Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: LWS
  • Model Number: LWS-3S7A-117(3S)
  • Number of Layers: Other
  • Base Material: FR-4
  • Copper Thickness: 1oz
  • Board Thickness: 1.6mm
  • Min. Hole Size: 0.25mm
  • Min. Line Width: 0.1mm(Flash Gold)/0.15mm(HASL)
  • Min. Line Spacing: 0.003"
  • Surface Finishing: HASL,lead free HASL,OSP,ENIG
  • Voltage: 11.1 V
  • cells in series: 3 S
  • Charging voltage: DC:12.6V CC/CV
  • Working current: 8A
  • Over current detection current: 10-30A
  • Pcb Size: L32*W29.8*T4.5mm
  • Application: e-bike,unicycle,powder tools,movable powder,toy's battery pack
  • Certificate: Can do CE,ROHS,ISO9001,ISO14001

Packaging & Delivery

Packaging Details Inner packing:Vaccum packing/Plastic bag.
Outer packing:Standard carton packing or packing per customer's requirements.
Delivery Time Shiped within 3-7 days after payment

1.Product Description



       Shenzhen Li-ion Battery Bodyguard Technology Co.,LTD
PCM Specifications  For 11.1V(3S)Li-ion Battery Packs
Model: LWS-3S7A-117(3S)
No.Test   itemCriterion
1VoltageCharging voltageDC:12.6V CC/CV
Balance voltage for single cell
2CurrentBalance current for single cell
Current consumption ≤20μA
Maximal continuous charging current8A
Maximal continuous Discharging current8A
3Over charge ProtectionOver charge detection voltage for single cell4.25±0.025V
Over charge detection delay time0.5S—1.5S
Over charge release voltage for single cell4.05±0.05V
4Over discharge protectionOver discharge detection voltage for single cell2.50±0.062V
Over discharge detection delay time10mS—150mS
Over discharge release voltage for single cell3.00±0.062V
5Over current protectionOver current detection voltage0.62V
Over current detection current10-30A
Detection delay time  5ms—20ms
Release conditionCut load
6Short protectionDetection conditionExterior short circuit
Detection delay time200-500us
Release conditionCut load
7ResistanceProtection  circuitry(MOSFET)≤20mΩ
8TemperatureOperating Temperature Range-40~+85℃
Storage Temperature Range-40~+125℃















Other products

















We professionally manufacture lithium polymer battery and pcb for more than 5 years in China.



We have cooperated with HP,Emerson tool,NIke,WD.



Our company is established in 2013.



Product Certificates CE ROHS.



Quality control system certificates:ISO9001,ISO14001



2.Our company



1.Complete products contract PCB assembly and manufacturing services



2.Circuir boards 2 to 30 layers PCB layout,fabrication, PCB assembly and box build



3.Active and passive components source is directly from original manufacturer



4.Enclosure cabinet case plastic injection molding,mental stamping,manufacture and assembly



5.High-precision 0201 size components SMT technology and lead-free



6.IC pre-program



7.Hight-precision E-Tasting





3.Services



1.after sales services



2.OEM,ODM,Customized Design



3.We can provide 24 hours service for you. We pride ourselves on our ability to custom tailor programs around



our  customers'needs. We take time to listen to your unique business needs and then set out to surpass them



4.FAQ



Payment Term:L/C,T/T,PayPal



Can provide variouse capacity and size is per your requirements.
